Digital mixing desk

The QU-5 is a compact digital mixing console designed by Allen & Heath, incorporating advanced audio technologies for a professional mixing experience.

QU-5 highlights

96 kHz FPGA XCVI processor for exceptional audio quality and ultra-low latency.
Built-in DEEP Processing for studio-quality dynamics and equalization.
17 motorized 100 mm faders and dedicated channel display for precise visual and tactile control.
Intuitive 7" touchscreen interface for quick access to all essential functions.
Extensive connectivity with 38 inputs, 24 outputs and Everything I/O-compatible SLink port.

QU-5 Key Features

XCVI & DEEP Processing

The QU-5 features the powerful 96 kHz XCVI processor, offering uncompromising audio precision. Thanks to DEEP Processing, you can apply professional dynamics and EQ processing directly to the channels, with no added latency.

Motorized, touch-sensitive control

With 17 motorized 100 mm faders and a 7" touchscreen interface, the QU-5 guarantees smooth navigation and optimum mixing precision. Each channel has its own display with an instant view of levels.

Intelligent mix assistance

Take advantage of Gain Assistant for perfect levels, Feedback Assistant to eliminate feedback, and a 32-channel Automatic Mic Mixer (AMM) for smooth conferences or broadcasts.

Redesigned user interface

Designed for demanding environments, the QU-5's user interface is quick and efficient to learn. It combines analog ergonomics with the power of digital for optimal workflow.

Modular connectivity and advanced recording

The SLink port enables connection to the Everything I/O ecosystem. 32x32 multichannel recording via USB-C, SD recording or USB-A stereo. Manage your mix remotely with Qu-MixPad and Qu4You.

Expert advice

A compact yet powerful console, perfectly suited to demanding professional environments.
High-quality audio processing with intuitive interface, ideal for both live and studio use.

Technical sheet

Number of channel mixing desk 6 and 8 channels
Number of channels 5 channels

Slice name display
- Yes
ME Personal Mixer compatible
- Yes
Color
- Black
Dimensions
- 440 x 476 x 213 mm
Integrated LED lighting
- No
USB stereo recording/playback
- Yes
Motorized faders
- Yes
Sampling frequency
- 96 kHz
Signal generator
- Yes
Number of fader layers
- 4
Number of faders
- 17
Number of assignable keys
- 8
Weight
- 10 kg
RTA
- Yes
Rackable
- With option
Cooling
- Active
Talkback
- Yes
Type
- Digital
Additional specifications
- XCVI 96kHz processor
- 38 inputs (32 Mono/Linkable, 3 Stereo)
- Stereo main LR output
- 12 Mixes (6 Mono/Linkable Aux, 6 Stereo Aux/Group)
- 2 Stereo Matrix
- 16 XLR/Jack "Combo" mic/line inputs
- 2 TRS stereo line inputs
- 1 Talkback
- 12 XLR outputs
- 2 TRS outputs
- 1 AES3 stereo digital output
- 128x128 intelligent SLink I/O port
- Stereo headphone output
- 6 Multi-FX engines with dedicated send and return channels
- 7-inch touchscreen
- 17 motorized 100 mm faders
- 4 channel layers
- 8 SoftKeys
- USB-A port for stereo audio recording/playback and data transfer
- USB-C audio interface for multichannel recording/playback (32x32)
- SD card port for multichannel audio recording/playback (16x16@96kHz, 32x32@48kHz)
- 12V lamp socket
- Configurable connection for single/double footswitch
- Configurable chromatic channel measurement LED
- 19" rack mounting (optional kit available)
- IEC mains connection with international power supply
- RJ45 network socket
- Remote control via free Qu-MixPad and Qu4You applications (Windows/MacOS/iOS/Android)
